Views: 0 Author: Site Editor Publish Time: 2026-08-11 Origin: Site
The GTWY Aluminium Alloy Aerial Lift Platform is a compact, double-mast aerial work platform designed for safe, stable lifting up to 18 meters. Built from high-strength aluminium alloy with a maximum load capacity of 300 kg, the GTWY series supports two operators with tools and is well-suited for indoor maintenance, installation, cleaning, and exhibition setup.
Manufactured by Niuli Machinery, a material handling equipment specialist founded in 1999 and ISO 9001-certified, the GTWY lift platform is available in seven height configurations and features both AC and DC hydraulic drive options.
The GTWY is a double-mast aluminium lifting platform that uses a synchronous dual-mast structure to provide smooth, stable vertical access. Its high-strength aluminium alloy construction keeps the unit lightweight enough to pass through standard doorways and elevator openings, while guide sliders minimize platform sway during operation.
Universal casters allow the unit to be repositioned freely across a job site. Telescopic outriggers provide stability on uneven surfaces by allowing operators to level the machine before lifting begins.
Double mast, synchronous lifting: Dual-mast structure with guide sliders ensures smooth, shake-free ascent and descent
High-strength aluminium alloy construction: Lightweight yet durable, enabling access through standard doors and elevators
Seven height options: Available in 6m, 8m, 10m, 12m, 14m, 16m, and 18m platform heights
Maximum load capacity of 300 kg: Supports two workers with tools simultaneously
Telescopic outriggers: Adjust to stabilize the platform on uneven or sloped ground
Universal casters: Allow easy repositioning across indoor work areas
AC/DC dual power system: Compatible with 110–230V AC mains or 12V DC battery operation
Integrated safety systems: Includes emergency stop button, overload protection device, and emergency lowering valve
Low failure rate: Simple structure reduces maintenance demands and downtime
Specification | GTWY802 | GTWY1002 | GTWY1202 |
|---|---|---|---|
Capacity (kg) | 300 | 250 | 200 |
Max Platform Height (m) | 8 | 10 | 12 |
Max Working Height (m) | 10 | 12 | 14 |
Platform Size (m) | 1.28 × 0.66 | 1.54 × 0.66 | 1.54 × 0.66 |
Overall Length (m) | 1.53 | 1.79 | 1.79 |
Overall Width (m) | 0.82 | 0.82 | 0.87 |
Overall Height (m) | 1.81 | 1.86 | 2.03 |
Outrigger Footprint (L/W m) | 1.65 × 1.66 | 2.13 × 1.89 | 2.13 × 1.94 |
Battery | 2 × 12V/65Ah | 2 × 12V/65Ah | 2 × 12V/65Ah |
Lifting Motor (AC) | 110–230V / 1.5KW | 110–230V / 1.5KW | 110–230V / 1.5KW |
Lifting Motor (DC) | 12V / 1.5KW | 12V / 1.5KW | 12V / 1.5KW |
Lifting Time (s) | 62 | 70 | 75 |
Lowering Time (s) | 43 | 46 | 54 |
Self Weight – AC (kg) | 630 | 730 | 825 |
Self Weight – DC (kg) | 670 | 770 | 865 |
Height configurations of 6m, 14m, 16m, and 18m are also available. Contact Niuli for full specifications on these models.
The GTWY double mast lift platform is primarily designed for indoor aerial work. Common applications include:
Facility maintenance: Overhead repairs, electrical work, and HVAC servicing
Equipment installation: Positioning machinery, lighting rigs, and structural components at height
Cleaning and inspection: Accessing ceilings, windows, and elevated surfaces safely
Exhibition and event setup: Assembling large displays, signage, and suspended installations
Warehousing and storage: Reaching elevated racking in logistics and distribution environments
The GTWY platform is better suited for indoor or sheltered environments than for rough outdoor terrain. Teams working on uneven indoor surfaces—such as warehouse floors with gradients—will benefit from the telescopic outrigger system that compensates for floor irregularities.
The GTWY series offers a practical balance between portability and load-bearing capacity. Its aluminium alloy mast construction keeps the unit lighter than comparable steel-frame platforms, which makes it easier to maneuver through buildings without heavy-duty transport equipment.
The dual-mast synchronous lifting mechanism—combined with precision guide sliders—delivers a level of platform stability that single-mast designs typically cannot match at equivalent heights. For teams that need reliable performance with minimal servicing overhead, the GTWY's straightforward mechanical design reduces the likelihood of failure and keeps maintenance straightforward.
Niuli Machinery holds ISO 9001:2000 quality management certification, and its products carry CE/GS certification issued by TÜV Germany. The GTWY platform is exported to customers across more than 120 countries.
Q: What is the maximum height the GTWY aluminium lift platform can reach?
The GTWY series is available in platform heights of 6m, 8m, 10m, 12m, 14m, 16m, and 18m. The maximum working height—which accounts for an operator's reach above the platform—is 2 meters higher than the listed platform height in each configuration.
Q: How does the GTWY platform maintain stability during lifting?
The GTWY uses a synchronous dual-mast structure fitted with guide sliders. These sliders constrain lateral movement throughout the lift cycle, reducing platform sway and ensuring consistent stability at height. Telescopic outriggers further stabilize the machine when operating on uneven ground.
Q: Can the GTWY aerial work platform fit through a standard doorway or elevator?
Yes. The compact overall width of 0.82m–0.87m (depending on model) and the lightweight aluminium alloy construction are specifically designed to allow the unit to be moved through standard building access points, including doorways and freight elevators.
Q: What safety devices are included as standard on the GTWY lift platform?
Every GTWY unit is equipped with an emergency stop button, an overload protection device, and an emergency lowering valve. These systems allow operators to halt the platform immediately or lower it safely in the event of a power failure or overload condition.
Q: Does the GTWY platform support both mains power and battery operation?
Yes. The GTWY is available with either AC (110–230V, 1.5KW) or DC (12V, 1.5KW) hydraulic drive motors, giving operators flexibility depending on whether mains power is accessible at the work site.
Q: How many operators can use the GTWY platform at one time?
The GTWY802 model supports a maximum load of 300 kg, which is sufficient for two workers with tools operating simultaneously. Capacity decreases to 250 kg for the GTWY1002 and 200 kg for the GTWY1202.
