EBY
NIULI
| Quantity: | |
|---|---|
Item | Unit | EBY30-Pro |
Model | - | EBY30-Pro |
Rated capacity | Kg | 3000 |
Power | - | Electric |
Operation type | - | Pedestrain |
Load center | mm | 600 |
Min. load height | mm | 75single/85Doubel |
Max. load height | mm | 185/195 |
Fork dimension | mm | 50/160/1150 |
Width of forks | mm | 550/680 |
Ground Clearance | mm | 25/35 |
Turning radius | mm | 1430 |
Overall length | mm | 1650 |
Overall height | mm | 1350 |
Battery capacity | V/Ah | 48V/27AH Lead-Acid/ 27AH or 40AH Lithium |
Charger | V/A | 48V/5A |
Overall weight | Kg | 186 |
What is the load capacity and key specifications of the EBY30PRO?
The EBY30PRO is a heavy-duty electric pallet truck with a rated capacity of 3000kg. Key specifications include: 48V power supply (options for 27Ah lead-acid or 27/40Ah lithium battery); overall weight of 186kg; electromagnetic braking; drive speed of 4km/h (loaded) / 4.2km/h (unloaded); gradeability of 8% (loaded) / 16% (unloaded); and low noise level below 70dB (EN12053 standard).
What are the main advantages of the EBY30PRO compared to traditional pallet trucks?
The EBY30PRO stands out with its dual power options (lead-acid or lithium battery), where the lithium version supports fast charging and "use while charging". It features low noise (＜70dB) and zero emissions, making it ideal for noise-sensitive environments like food, pharmaceutical, and electronics warehouses. The compact design (overall length 1650mm) enables flexible operation in narrow aisles.
What maintenance is required for the EBY30PRO, and what is the typical service life of its key components?
Regular maintenance focuses on battery care, hydraulic system checks, and tire inspection. The lithium battery has a cycle life of over 1500 times, while the Curtis controller (imported core component) ensures stable and durable performance. It is recommended to replace hydraulic oil regularly and check tire wear to extend the machine’s service life.
Is the EBY30PRO suitable for indoor and semi-outdoor use? What are its operational limits?
Designed primarily for indoor warehouse environments, it excels in smooth floors and quiet operations. It is not recommended for rough outdoor terrain or heavy rainy conditions. The minimum ground clearance is 25-35mm, and the turning radius is 1430mm, ensuring flexibility in tight spaces.
What safety features does the EBY30PRO come equipped with?
Key safety features include electromagnetic braking for instant stops; an emergency stop switch for immediate power cut; anti-fatigue handle design for operator comfort; and overload protection to prevent damage from excessive weight. These features ensure safe and reliable operation in various warehouse scenarios.
