CPD
NIULI
| Quantity: | |
|---|---|
No. | Item | Symbol | Unit | CPD45E | CPD50E | CPD60E | |||
Lithium Battery | Lead-acid Battery | Lithium Battery | Lead-acid Battery | Lithium Battery | Lead-acid Battery | ||||
General Parameters | |||||||||
1.01 | Model | - | - | CPD45E | CPD45E | CPD50E | CPD50E | CPD60E | CPD60E |
1.02 | Rated Capacity | Q | Kg | 4500 | 4500 | 5000 | 5000 | 6000 | 6000 |
1.03 | Load Center Distance | C | mm | 500 | 500 | 500 | 500 | 600 | 600 |
1.04 | Power Type | - | - | Lithium Battery | Lead-acid Battery | Lithium Battery | Lead-acid Battery | Lithium Battery | Lead-acid Battery |
1.05 | Driving Type | - | - | Seated Type | Seated Type | Seated Type | Seated Type | Seated Type | Seated Type |
1.06 | Wheel Base | L1 | mm | 2050 | 2050 | 2050 | 2050 | 2350 | 2350 |
Tyre Parameters | |||||||||
2.01 | Tyre Type | - | - | Solid Tyre | Solid Tyre | Solid Tyre | Solid Tyre | Solid Tyre | Solid Tyre |
2.02 | Wheel Number (Front/Rear) | - | - | 2×/2 | 2×/2 | 2×/2 | 2×/2 | 4×/2 | 4×/2 |
2.03 | Front Tread | W3 | mm | 1280 | 1280 | 1280 | 1280 | 1470 | 1470 |
2.04 | Rear Tread | W2 | mm | 1190 | 1190 | 1190 | 1190 | 1190 | 1190 |
2.05 | Front Tyre Specification | - | - | 250-15 | 250-15 | 28X12.5-15 | 28X12.5-15 | 8.25-15 | 8.25-15 |
2.06 | Rear Tyre Specification | - | - | 7.00-12 | 7.00-12 | 7.00-12 | 7.00-12 | 250-15 | 250-15 |
Dimension Parameters | |||||||||
3.01 | Front Overhang | L2 | mm | 565 | 565 | 565 | 565 | 580 | 580 |
3.02 | Mast Tilting Angle (Front/Rear) | α/β | ° | 6/12 | 6/12 | 6/10 | 6/10 | 6/10 | 6/10 |
3.03 | Min. Mast Height (Retracted) | H1 | mm | 2250 | 2250 | 2250 | 2250 | 2500 | 2500 |
3.04 | Free Lifting Height | H3 | mm | 150 | 150 | 150 | 150 | 165 | 165 |
3.05 | Max. Lifting Height | H | mm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
3.06 | Max. Height (Lifted) | H2 | mm | 4280 | 4280 | 4280 | 4280 | 4420 | 4420 |
3.07 | Overhead Guard Height | H4 | mm | 2255 | 2255 | 2255 | 2255 | 2470 | 2470 |
3.08 | Fork Size (Length×Width×Thickness) | L×W×T | mm | 1070×150×50 | 1070×150×50 | 1070×150×50 | 1070×150×50 | 1220×150×60 | 1220×150×60 |
3.09 | Overall Length (Excluding Fork) | L | mm | 3135 | 3135 | 3135 | 3135 | 3452 | 3452 |
3.10 | Overall Width | W1 | mm | 1400 | 1400 | 1400 | 1400 | 2002 | 2002 |
3.11 | Turning Radius | r | mm | 2900 | 2900 | 2900 | 2900 | 3180 | 3180 |
3.12 | Mast Ground Clearance | H5 | mm | 140 | 140 | 140 | 140 | 160 | 160 |
3.13 | Chassis Ground Clearance (Loaded) | H6 | mm | 145 | 145 | 145 | 145 | 170 | 170 |
3.14 | Fork Adjustable Width (Max./Min.) | W5 | mm | 1580/300 | 1580/300 | 1580/300 | 1580/300 | 1840/300 | 1840/300 |
Performance Parameters | |||||||||
4.01 | Traveling Speed | - | km/h | 13/15 | 13/15 | 13/15 | 13/15 | 14/16 | 14/16 |
4.02 | Lifting Speed (Loaded/Unloaded) | - | mm/s | 300/400 | 300/400 | 280/400 | 280/400 | 350/450 | 350/450 |
4.03 | Lowering Speed (Loaded) | - | mm/s | ＜600 | ＜600 | ＜600 | ＜600 | ＜600 | ＜600 |
4.04 | Gradeability (Loaded) | - | % | 15 | 15 | 15 | 15 | 15 | 15 |
Weight Parameters | |||||||||
5.01 | Total Weight (With Battery) | - | Kg | 6250 | 6700 | 6780 | 7200 | 9200 | 9450 |
Battery Parameters | |||||||||
6.01 | Battery Voltage/Capacity | - | V/Ah | 80/410 | 80/560 | 80/460 | 80/630 | 76.8/608 | 80/700 |
6.02 | Battery Weight | - | Kg | 374 | 1265 | 380 | 1565 | 510 | 1865 |
Motor & Controller Parameters | |||||||||
7.01 | Drive Motor Power (S2-60) | - | Kw | 17 | 17 | 18 | 18 | 30 | 30 |
7.02 | Lift Motor Power (S3-15%) | - | Kw | 26 | 26 | 26 | 26 | 2×26 | 2×26 |
What are the core advantages of NIULI electric counterbalance forklifts compared with peer‑brand models?
NIULI electric forklifts adopt mature Curtis AC control system, high‑strength integral mast frame, heavy‑duty solid tires and AMP waterproof connectors. The whole machine undergoes strict load fatigue test. It delivers stable output, low failure rate and good adaptability for multi‑shift heavy‑load working conditions, with competitive total cost of ownership.
Can NIULI lithium‑ion forklift work in cold‑storage environment? What special configurations are required?
Yes, it supports cold‑storage application. Optional configurations include battery heating system, low‑temperature resistant hydraulic oil L‑HV32, anti‑condensation treatment for electrical components, cold‑resistant sealing pieces. These options effectively prevent condensation and low‑temperature performance attenuation.
What is the difference between NIULI lead‑acid version and lithium‑battery version for the same forklift model?
Lithium‑battery version features fast‑charging, opportunity‑charging support, zero‑maintenance battery, lighter battery weight and longer service life. Lead‑acid version has lower initial purchase cost but requires regular water filling and dedicated charging room. Overall dimension and lifting performance keep consistent on same model.
Yes, it is reserved for multi‑attachment installation. Common options include side shifter, fork positioner, drum lifter, carton clamp, bale clamp. We will adjust hydraulic circuit and capacity curve according to selected attachment.
NIULI provides general spare‑parts list together with each shipment. We support global spare‑parts delivery. We supply original core components including controller, motor, hydraulic pump. We also offer technical documents, wiring diagrams and remote online guidance for local dealers & end‑users.
What safety protection functions are equipped on NIULI seated‑type electric forklift?
Standard safety features contain seat‑sensor interlock, overload protection, hydraulic overflow protection, low‑voltage cut‑off for battery, emergency stop button, tilt and speed limitation at high lifting height, fault‑code display on instrument panel.
