11m lifting machine mobile electric scissor lift
Mobile scissor lift table adopts scissor type mechanic structure to bring high stability after being elevated. The wide operation platform and high loading ability has made wider aloft work arrange and is suitable for simultaneous multi-worker operation.
Mobile Scissor Lifting Table :
Model | Capacity(kg) | Rated height(mm) | Low height(mm) | Platform size(mm) | Elevating time(s) | Motor power(kw) | Voltage(v) | Self weight (kg) |
SJY0.3-6 | 300 | 6000 | 1200 | 1780x840 | 50 | 1.5 | 380v/50hz | 1000 |
SJY0.5-6 | 500 | 6000 | 1300 | 1780x840 | 50 | 1.5 | 380v/50hz | 1100 |
SJY1-6 | 1000 | 6000 | 1400 | 1780x1000 | 60 | 2.2 | 380v/50hz | 1400 |
SJY0.3-9 | 300 | 9000 | 1400 | 2000x1000 | 70 | 2.2 | 380v/50hz | 1400 |
SJY0.5-9 | 500 | 9000 | 1400 | 2000x1000 | 70 | 2.2 | 380v/50hz | 1500 |
SJY1-9 | 1000 | 9000 | 1500 | 2000x1200 | 75 | 3.7 | 380v/50hz | 1850 |
SJY0.3-11 | 300 | 11000 | 1600 | 2150x1200 | 70 | 2.2 | 380v/50hz | 2000 |
SJY0.5-11 | 500 | 11000 | 1600 | 2150x1200 | 80 | 2.2 | 380v/50hz | 2100 |
SJY0.3-12 | 300 | 12000 | 1600 | 2350x1350 | 85 | 3.7 | 380v/50hz | 2200 |
SJY0.5-12 | 500 | 12000 | 1600 | 2350x1350 | 90 | 3.7 | 380v/50hz | 2300 |
SJY0.3-14 | 300 | 14000 | 2000 | 2600x1500 | 120 | 3.7 | 380v/50hz | 2800 |
SJY0.5-14 | 500 | 14000 | 2000 | 2600x1500 | 130 | 3.7 | 380v/50hz | 3100 |
SJY0.3-16 | 300 | 16000 | 2100 | 2800x1500 | 180 | 3.7 | 380v/50hz | 3200 |
