CTQR
NIULI
| Quantity: | |
|---|---|
Model | - | CTQR15D-45S | CTQR20-45S |
Power Type | - | Electric | Electric |
Operation Type | - | Standing Type | Standing Type |
Load Capacity | Q(kg) | 1500 | 2000 |
Load Center | C(mm) | 500 | 500 |
Front Overhang | X(mm) | 145 | 145 |
Wheelbase | Y(mm) | 1399 | 1584 |
Service Weight (With Battery) | kg | 2200 | 2250 |
Wheel Type | - | PU | PU |
Wheel tread, Front wheel | b10(mm) | 978 | 978 |
Wheel tread, Rear wheel | b11(mm) | 804 | 804 |
Mast Height, Lowered | h1(mm) | 2120 | 2120 |
Lifting Height | h3(mm) | 4500 | 4500 |
Height, mast extended | h4(mm) | 5485 | 5485 |
Height of overhead guards | h14(mm) | 2280 | 2280 |
Fork face min.ground clearance | h13(mm) | 35 | 40 |
Fork tilting angle Front/Rear | α/β (°) | 3/5 | 3/5 |
Overall Length | l1(mm) | 2272 | 2385 |
Body Length | l2(mm) | 1703 | 1888 |
Overall Width | b1(mm) | 1098 | 1098 |
Fork Size | s/e/l(mm) | 35/100/1070 | 40/122/1070 |
Fork Spread | b5(mm) | 210-705 | 244-705 |
Reach Distance | L(mm) | 500 | 600 |
Min.ground clearance | m2(mm) | 77 | 77 |
Aisle Width for Pallet 1000*1200 crossways | Ast(mm) | 2771 | 2880 |
Min.turning radius | Wa(mm) | 1600 | 1781 |
Max. travel speed (Unladen/Laden) | km/h | 5/4 | 5/4 |
Lifting Speed (Unladen/Laden) | m/s | 0.135/0.110 | 0.135/0.100 |
Lowering Speed (Unladen/Laden) | m/s | 0.085/0.132 | 0.085/0.140 |
Max.grade Ability (Unladen/Laden) | % | 8/4 | 8/4 |
Service Brake | - | Electromagnetic | Electromagnetic |
Drive Motor | kw | 2.5 | 2.5 |
Lift Motor | kw | 3 | 3 |
Battery Type | - | Lead Acid | Lead Acid |
Battery voltage/nominal capacity | V/Ah | 24V280Ah | 24V280Ah |
Charger | V/A | 24V/40A | 24V/40A |
Type of drive control | - | AC | AC |
| Sound level at the driver's ear acc. to EN12053 | dB(A) | 75 | 75 |
NIULI's core products focus on the field of warehousing, logistics and automotive equipment, mainly including manual pallet trucks, electric forklifts, aerial work platforms, vehicle tailgates, hydraulic dock levelers, etc. With a complete range of models and specifications, they can meet the material handling, loading and unloading, and aerial work needs of various scenarios such as industry, logistics and warehousing. At the same time, related products such as cable accessories are also provided.
NIULI's products have passed many authoritative certifications such as ISO9001 quality management system certification and European CE/GS certification, and the production process strictly controls quality. All products come with a 1-year warranty service, and a complete domestic and foreign after-sales network is available to provide online technical support, fault diagnosis, parts replacement and other services to ensure the long-term stable use of the products.
Customized services are supported. NIULI has a professional R&D team and customized production capabilities. According to the specific needs of customers, it can customize product specifications, materials (such as aluminum alloy, steel), load capacity, size, etc. At the same time, it can also provide OEM/ODM services to meet the personalized use needs of different industries and scenarios.
NIULI has a large-scale production base covering an area of 500 mu, equipped with complete production facilities such as automatic welding production lines and automatic spraying lines. It has nearly 1,000 employees and more than 200 various middle and senior professional and technical personnel. The annual output can reach 400,000 units (pieces), and the products have been exported to more than 120 countries and regions around the world, covering Asia, Europe, the Americas, Africa and other regions, enjoying a good reputation in domestic and foreign markets.
If a product fails, you can first refer to the product manual for simple fault diagnosis (such as exhausting the hydraulic pallet truck, checking hydraulic oil, etc.); if it cannot be solved, you can contact NIULI's official after-sales team to enjoy online fault guidance services. If on-site maintenance is needed, after-sales personnel will arrange on-site service according to the region. At the same time, the company provides sufficient parts supply to ensure that faults are solved quickly and reduce the impact of service interruption.
