NIULI 3000kg Isuzu diesel engine forklift truck with CE
Company Profiles
Niuli Machinery Manufacture CO.,Ltd is one of the biggest forklift and material and handling Equipments suppliers in China, The products cover warehousing forklift, electric forklift, Hand Pallet truck, Scissor lift table, Container dock Ramp. Clean Machine.Niuli has become the leader in the field of new forklift leasing in GuangDong.
Product Characteristics
l Strong power: Use high-power engine to provide sufficient energy
l Smooth drive system: Easy operation, reliable gearbox, manual or electronic shift available
l Wide-view design: Special wide-view mast design improves the productivity and safety
l Double air filter: Unique double air intake system ensures lower noise and longer service life
l Safety guarantee: Use electromagnetic main switch ensures the safety of electrical system
l Clean appearance: 3D surface modeling makes it clean and beautiful
| General | 1 | Model | CPC30/CPCD30 | |||||
| 2 | Power Type | Diesel/GAS | ||||||
| 3 | Rated capacity | Kg | 3000 | |||||
| 4 | Load center | mm | 500 | |||||
| Charactertic | 5 | Lifting height | mm | 3000 | ||||
| 6 | Fork size | mm | 1070*122*40 | |||||
| 7 | Mast Tilt Angle | Deg | 6°/12° | |||||
| 8 | Front Overhang(Wheel center to fork face) | mm | 500 | |||||
| 9 | Ground Clearance(Bottom Of Mast) | mm | 126 | |||||
| 10 | Overall Dimension | Overall length(with/without fork) | mm | 3790/2700 | ||||
| 11 | Overall width | mm | 1230 | |||||
| 12 | Mast lowered height | mm | 2105 | |||||
| 13 | MastExtended height(with backrest) | mm | 4110 | |||||
| 14 | Overhead guard height | mm | 2140 | |||||
| 15 | Turning Radius(outside) | mm | 2415 | |||||
| 16 | Min. intersecting aisle | mm | 2500 | |||||
| Performance | 17 | Speed | Travel(Full/Empty load) | km/h | 18/19 | |||
| 18 | Lifting(Full/Empty load) | mm/s | 460/540 | |||||
| 19 | Max.Gradeability | % | 20 | |||||
| Chassis | 20 | Tire | Front | 28x9-15-12PR | ||||
| 21 | Rear | 6.50-10-10PR | ||||||
| 22 | Wheelbase | mm | 1650 | |||||
| 23 | Self Weight | kg | 4280 | |||||
| Transmission | 24 | Battery | Voltage/Capacity | V/Ah | 12/120 | |||
| 25 | Engine | Model | C240 | C490BPG | ||||
| 26 | Manufacturer | ISUZU | XinChang | |||||
| 27 | Rated output/r.p.m | kW/rpm | 34.3/2500 | 34.3/2500 | ||||
| 28 | Rated torque/r.p.m | Nm/rpm | 137.7/1800 | 160/1800-2000 | ||||
| 29 | No. of cylinder | 4 | 4 | |||||
| 30 | Bore x Stroke | mm | 86x102 | 90x105 | ||||
| 31 | Displacement | cc | 2369 | 2670 | ||||
| 32 | Fuel Tank capacity | L | 60 | 60 | ||||
| 33 | Transmission | Machanical/Hydraulic | ||||||
| 34 | Operation Pressure for Attachment | Mpa | 17.5 | |||||
